EPSON L1440 Printhead
Compatible with EPSON V-series Printers
Technical Support for Installation & Maintenance
Total Solution for related accessories.
Save your money with our professional works!
EPSON L1440 series Printhead
Original products of EPSON
An Entry level 1 inch Inkjet Printhead with 8 Colors!
Features:
1. MACH Technology
MACH (Multi-Layer Actuator Head) technology can realize high precision and high density (360npi / 2rows).
2. Miniaturization
Possible to arrange the printhead width direction in a miniaturization manner when using a staggered arrangement.
3. Support for grey-scale
Epson's unique Variable Sized Droplet Technology (VSDT) delivers smooth gradation by freely control to eject the droplet volume.
4. Multi-colors
Ink ejection with 4 colors at 360 dpi / color or 6 colors at 180 dpi/color is possible.
5. High durability
Micro Piezo print head has proven high durable and extended service life by Epson's industrial printers.
Product Specifications
|
Product Name |
L1440-U2 |
L1440-A1 |
||
|
Ink Type |
UV / Eco Solvent |
Aqueous |
||
|
Width x Depth x Height * |
60.4 x 46.9 x 71.1 mm |
|||
|
Weight * |
97 g |
|||
|
Number of nozzle |
1440 |
|||
|
Nozzle pitch / nozzle row |
1/180 inch |
|||
|
Nozzle rows |
8 rows |
|||
|
Nozzle Resolution |
180 dpi /row 360 dpi/2 rows |
|||
|
Max. number of color inks |
8 colors |
|||
|
Effective print width |
25.4mm (1 inch) |
|||
|
Droplet ejection performance * |
Binary |
10pl 40 kHz |
9.2 pl at 46.4 kHz |
|
|
4 levels grey scale |
4.5, 10, 19pl at 20 kHz |
3.4, 9.2, 16pl at 23.2 kHz |
||
|
Viscosity range * |
6-8mPa.s |
4-5mPa.s |
||
|
Ink recirculation |
No recirculation. |
|||
|
Internal heater |
YES |
|||
|
Positioning Mechanism |
Reference hole |
|||
|
lifetime |
106 billion jetting; 1500 times Cleaning under 40KPa |
|||
|
Country of Original |
Japan |
|||
*Epson's unique waveform design allows for a variety of greyscale and droplet size combinations.
*Product Specifications and document description are subject to change without notice.
Printer Compatibility:
This L1440 series printhead configured on the EPSON V series printer. Only a few Chinese brand printer use that printhead. For Details you can consult us directly.
The other parts related with this printhead, such as electronic boards, filters, dampers, capping station, data cables, inks, etc. you can also email us for the best.
Technical Support:
All products we sell the key is technical support.
Technical support for the installation & Maintenance.
Technical consult is always free.
Total solution for your business, saving your money with our professional works.
